Nissan Patrol GQ-GU Barra Conversion Kit
SKU: ecnvngqgu_barra
| Conversion Kit Includes | ||
|---|---|---|
| Part | Part # | Qty |
| Bellhousing | bh115 | 1 |
| Bolt Kit | bh115-bolt-kit2 | 1 |
| Engine Mounts - BOLT ON | 1 | |
| High Mount Altrenator & Power Steering Relocation Kit | himntaltpsreloc | 1 |
| Sandwich Plate | crs241741 | 1 |
| Slave Cylinder Spacer | crs237489 | 1 |
| Spigot Bush | sb31a | 1 |
| EXEDY Clutch Kit | bh115ckit | 1 |
The Bellhousing HAS been Designed to Use a Factory Ford BA or BF 2 Bolt 6 Cylinder Starter Motor
A ZD30 RE4 Auto Crossmember is needed for ALL Models, The ZD30 RE4 Auto Drive Shafts are also needed.
Exedy Clutch 280mm Kit Is included with this conversion kit.
Clutch Cover clamp load - 1500kg
Clutch Torque Capacity at Flywheel - 1125NM
(With Exedy's 15% Factory of safety 955NM)
Also comes with a Genuine Nissan Thrust Bearing carrier and Japanese Thrust Bearing.
A ZD30 RE4 Auto Crossmember is needed for ALL Models, The ZD30 RE4 Auto Drive Shafts are also needed.
This is to give you the best possible Sump & Firewall Clearance
For all Models apart from ZD30 you will also need a Remote oil filter adaptor. ($195.00 extra)
Kit is sold using Bolt in engine mounts (previously Sold by AZ Kruger Fabrications)
| Conversion Kit Includes | ||
|---|---|---|
| Part | Part # | Qty |
| Bellhousing | bh115 | 1 |
| Bolt Kit | bh115-bolt-kit2 | 1 |
| Engine Mounts - BOLT ON | 1 | |
| High Mount Altrenator & Power Steering Relocation Kit | himntaltpsreloc | 1 |
| Sandwich Plate | crs241741 | 1 |
| Slave Cylinder Spacer | crs237489 | 1 |
| Spigot Bush | sb31a | 1 |
| EXEDY Clutch Kit | bh115ckit | 1 |
| Conversion Kit Includes | ||
|---|---|---|
| Part | Part # | Qty |
| Bellhousing | bh115 | 1 |
| Bolt Kit | bh115-bolt-kit2 | 1 |
| Engine Mounts - BOLT ON | 1 | |
| High Mount Altrenator & Power Steering Relocation Kit | himntaltpsreloc | 1 |
| Sandwich Plate | crs241741 | 1 |
| Slave Cylinder Spacer | crs237489 | 1 |
| Spigot Bush | sb31a | 1 |
| EXEDY Clutch Kit | bh115ckit | 1 |
| Conversion Kit Includes | ||
|---|---|---|
| Part | Part # | Qty |
| Bellhousing | bh115 | 1 |
| Bolt Kit | bh115-bolt-kit2 | 1 |
| Engine Mounts - BOLT ON | 1 | |
| High Mount Altrenator & Power Steering Relocation Kit | himntaltpsreloc | 1 |
| Sandwich Plate | crs241741 | 1 |
| Slave Cylinder Spacer | crs237489 | 1 |
| Spigot Bush | sb31a | 1 |
| EXEDY Clutch Kit | bh115ckit | 1 |
| SKU | ecnvngqgu_barra |
